Bipartite Graph Validation
- Given an undirected graph
- Determine if it is bipartite
- nodes can be colored in one of 2 colors
- no adjacent node are the same color
The point:
- For each node we color blue, color all of its neighbors orange et vice versa
- DFS
- The graph may not be fully connected
Complexity :
| Time | Space |
|---|---|
| O(n + e) | O(n) |
- O(n + e) in time because we create n nodes and traverse e edges
- O(n) in space because the size of the recursive call stack (can grow up to n). Colors array contributes in O(n)
First implementation
About Rust :
- Based on the version using
GraphNodeandGraphclasses - Pay some attention to
for &neighbor in &self.nodes[node].neighbors {... - YES : tested on the Rust Playground
mod graph {
use std::collections::HashSet;
struct GraphNode {
val: usize,
neighbors: Vec<usize>,
}
impl GraphNode {
fn new(val: usize, neighbors: Vec<usize>) -> Self {
Self { val, neighbors }
}
}
pub struct Graph {
nodes: Vec<GraphNode>,
}
impl Graph {
pub fn new() -> Self {
Self { nodes: Vec::new() }
}
pub fn from_adjacency_list(adj_list: &[Vec<usize>]) -> Self {
let mut graph = Graph::new();
for (i, neighbors) in adj_list.iter().enumerate() {
graph.nodes.push(GraphNode::new(i, neighbors.clone()));
}
graph
}
pub fn print(&self, node: usize) {
let mut visited = HashSet::new();
self.print_recursive(node, &mut visited);
}
fn print_recursive(&self, node: usize, visited: &mut HashSet<usize>) {
if visited.contains(&node) {
return;
}
visited.insert(node);
println!("Node {} has neighbors {:?}", node, &self.nodes[node].neighbors);
for &neighbor in &self.nodes[node].neighbors {
self.print_recursive(neighbor, visited);
}
}
pub fn bipartite_graph_validation(&self) -> bool{
let mut colors = vec![0; self.nodes.len()]; // unvisited
// Determine if each graph component is bipartite
for i in 0..self.nodes.len(){
if colors[i] == 0 && !self.dfs(i, 1, &mut colors){
return false;
}
}
true
}
fn dfs(&self, node : usize, color : i32, colors: &mut Vec<i32>) -> bool{
colors[node] = color;
for &neighbor in &self.nodes[node].neighbors{
// If current neighbor has same color the graph is NOT bipartite
if colors[neighbor]==color{
return false;
}
// If current neighbor is not colored, color it with the other color and continue the DFS
if (colors[neighbor]==0) && !self.dfs(neighbor, -color, colors){
return false;
}
}
true
}
}
}
use graph::Graph;
fn main() {
// 0 - 1
// / \
// 4 2
// \
// 3
let adjacency_list = [
vec![1, 4],
vec![0, 2],
vec![1], // try `vec![1, 3],` to get false
vec![4],
vec![0, 3],
];
let my_graph = Graph::from_adjacency_list(&adjacency_list);
let start_node = 0;
my_graph.print(start_node); // Node 0 has neighbors [1, 4]
// ...
println!("{}", my_graph.bipartite_graph_validation()); // true
}
V2
About Rust :
- Remove the
.print()method - Use an enum for colors
valis renamed asidthenidis deleted because never used- I let the previous line in comments
- YES : tested on the Rust Playground
mod graph {
#[derive(PartialEq, Eq, Clone, Copy)]
enum Color {
Unvisited,
Orange,
Blue,
}
struct GraphNode {
// id: usize,
neighbors: Vec<usize>,
}
impl GraphNode {
// fn new(id: usize, neighbors: Vec<usize>) -> Self {
fn new(neighbors: Vec<usize>) -> Self {
// Self { id, neighbors }
Self {neighbors }
}
}
pub struct Graph {
nodes: Vec<GraphNode>,
}
impl Graph {
pub fn new() -> Self {
Self { nodes: Vec::new() }
}
pub fn from_adjacency_list(adj_list: &[Vec<usize>]) -> Self {
let mut graph = Graph::new();
// for (i, neighbors) in adj_list.iter().enumerate() {
for neighbors in adj_list.iter() {
graph
.nodes
//.push(GraphNode::new(i, neighbors.clone()));
.push(GraphNode::new(neighbors.clone()));
}
graph
}
pub fn bipartite_graph_validation(&self) -> bool {
let mut colors = vec![Color::Unvisited; self.nodes.len()];
for i in 0..self.nodes.len() {
if colors[i] == Color::Unvisited
&& !self.dfs(i, Color::Orange, &mut colors)
{
return false;
}
}
true
}
fn dfs(&self, node: usize, color: Color, colors: &mut Vec<Color>) -> bool {
colors[node] = color;
let opposite = match color {
Color::Orange => Color::Blue,
Color::Blue => Color::Orange,
Color::Unvisited => unreachable!(),
};
for &neighbor in &self.nodes[node].neighbors {
match colors[neighbor] {
c if c == color => return false, // same color → not bipartite
Color::Unvisited => {
if !self.dfs(neighbor, opposite, colors) {
return false;
}
}
_ => (), // already visited with the right color
}
}
true
}
}
}
use graph::Graph;
fn main() {
// 0 - 1
// / \
// 4 2
// \
// 3
let adjacency_list = [
vec![1, 4],
vec![0, 2],
vec![1], // try vec![1, 3] for a non-bipartite example
vec![4],
vec![0, 3],
];
let my_graph = Graph::from_adjacency_list(&adjacency_list);
println!("{}", my_graph.bipartite_graph_validation()); // true
}
About Rust :
- Same as above but commented lines are removed
- Preferred solution?
- YES : tested on the Rust Playground
mod graph {
#[derive(PartialEq, Eq, Clone, Copy)]
enum Color {
Unvisited,
Orange,
Blue,
}
struct GraphNode {
neighbors: Vec<usize>,
}
impl GraphNode {
fn new(neighbors: Vec<usize>) -> Self {
Self { neighbors }
}
}
pub struct Graph {
nodes: Vec<GraphNode>,
}
impl Graph {
pub fn new() -> Self {
Self { nodes: Vec::new() }
}
pub fn from_adjacency_list(adj_list: &[Vec<usize>]) -> Self {
let mut graph = Graph::new();
for neighbors in adj_list.iter() {
graph.nodes.push(GraphNode::new(neighbors.clone()));
}
graph
}
pub fn bipartite_graph_validation(&self) -> bool {
let mut colors = vec![Color::Unvisited; self.nodes.len()];
for i in 0..self.nodes.len() {
if colors[i] == Color::Unvisited && !self.dfs(i, Color::Orange, &mut colors) {
return false;
}
}
true
}
fn dfs(&self, node: usize, color: Color, colors: &mut Vec<Color>) -> bool {
colors[node] = color;
let opposite = match color {
Color::Orange => Color::Blue,
Color::Blue => Color::Orange,
Color::Unvisited => unreachable!(),
};
for &neighbor in &self.nodes[node].neighbors {
match colors[neighbor] {
c if c == color => return false, // same color → not bipartite
Color::Unvisited => {
if !self.dfs(neighbor, opposite, colors) {
return false;
}
}
_ => (), // already visited with the right color
}
}
true
}
}
}
use graph::Graph;
fn main() {
// 0 - 1
// / \
// 4 2
// \
// 3
let adjacency_list = [
vec![1, 4],
vec![0, 2],
vec![1], // try vec![1, 3] for a non-bipartite example
vec![4],
vec![0, 3],
];
let my_graph = Graph::from_adjacency_list(&adjacency_list);
println!("{}", my_graph.bipartite_graph_validation()); // true
}
