Invert Binary Tree

  • Invert a binary tree and returns its root
    • invert => mirror image

TODO :

  • Rust : come back on .as_mut(), .as_deref()

Recursive

The point:

  • Child are swapped relative to their parent node
  • The swap of the left and right child happens to each node
    • all nodes under the moved child are moved as well
  • DFS

Complexity :

Time Space
O(n) O(n)
  • O(n) in time because we traverse each node exactly once
  • O(n) in space because of the size of the recursive stack which is the height of the tree (n at its max.)

About Rust :

  • Based on V2 (see 189_intro.ipynb) for easy tree building
  • &mut everywhere
  • Here invert_binary_tree_recursive does not return root but it acts in place
  • YES : tested on the Rust Playground
type Link = Option<Box<TreeNode>>;

struct TreeNode {
    value: i32,
    left: Link,
    right: Link,
}

impl TreeNode {
    fn new(value: i32) -> Self {
        TreeNode {
            value,
            left: None,
            right: None,
        }
    }

    // Add child on the left
    fn left(mut self, node: TreeNode) -> Self {
        self.left = Some(Box::new(node));
        self
    }

    // Add child on the right
    fn right(mut self, node: TreeNode) -> Self {
        self.right = Some(Box::new(node));
        self
    }
}

// since there is a swap, the link must be mutable then &mut must be propagated in the body of the function
fn invert_binary_tree_recursive(link: &mut Link){
    if let Some(node) = link {
        std::mem::swap(&mut node.left, &mut node.right);    // process current node
        invert_binary_tree_recursive(&mut node.left);       // left
        invert_binary_tree_recursive(&mut node.right);      // right
    }
}

fn preorder_print(link: &Link) {
    if let Some(node) = link {
        print!("{} ", node.value);      // Process current node
        preorder_print(&node.left);     // Traverse left child
        preorder_print(&node.right);    // Traverse right child
    }
}

fn main() { // no main() if this code runs in a Jupyter cell
    // Build the tree:
    //         5
    //      /     \
    //     1       8
    //    / \       \
    //   7   6       4
    let tree = TreeNode::new(5)
        .left(
            TreeNode::new(1)
                .left(
                    TreeNode::new(7)
                )
                .right(
                    TreeNode::new(6)
                )
        )
        .right(
            TreeNode::new(8)
                .left(
                    TreeNode::new(4)
                ) // no child on the right
        );

    let mut root_link = Some(Box::new(tree));
    invert_binary_tree_recursive(&mut root_link);
    preorder_print(&root_link); // 5 8 4 1 6 7
} // end of local scope OR end of main()

Iterative

The point:

  • The recursive call stack is a stack
  • Here we use our own stack
  • DFS

Complexity :

Time Space
O(n) O(n)
  • O(n) in time because we traverse each node exactly once
  • O(n) in space because of the size of the stack which is the height of the tree (n at its max.)

About Rust :

  • Based on V2 (see 189_intro.ipynb) for easy tree building
  • Some(node) = link.as_mut()
  • .as_mut() everywhere
  • Contrary to what is done in the book, invert_binary_tree_iterative() does not return root but it acts in place
  • YES : tested on the Rust Playground

First idea that does not work :

fn invert_binary_tree_iterative(link: &mut Link) {
    let mut my_stack = Vec::new();

    if let Some(node) = link{
    // if let Some(node) = link.as_mut() {
        my_stack.push(node);

        while let Some(current) = my_stack.pop() {
            std::mem::swap(&mut current.left, &mut current.right);

            if let Some(left_node) = current.left{
                my_stack.push(left_node);
            }

            if let Some(right_node) = current.right{
                my_stack.push(right_node);
            }
        }
    }
}
  • On the line std::mem::swap(&mut node.left, &mut node.right); we must be able to mutate node.left and node.right.
  • If we write if let Some(node) = link {
    • Since link is of type &mut Link
    • This mean link is, in fact, of type &mut Option<Box<TreeNode>>
    • When we write if let Some(node) = link {
      • Rust is going through a code similar to :
match link {
    Some(node) => {
        // node is of type & Box<TreeNode>
        // it is read only, NOT mutable
    }
    None => {
        // Do nothing or handle the None case
    }
}

What we need is something like :

match link.as_mut() {
    Some(node) => {
        // node is now of type &mut Box<TreeNode>
        // it is mutable
        let tree_node: &mut TreeNode = node.as_mut();
    }
    None => {
        // Nothing to do
    }
}

This is why .as_mut() is used in invert_binary_tree_iterative() since it provides a mutable access to content of the reference

fn invert_binary_tree_iterative(link: &mut Link) {
    let mut my_stack = Vec::new();

    if let Some(node) = link.as_mut() {
        my_stack.push(node);

        while let Some(current) = my_stack.pop() {
            std::mem::swap(&mut current.left, &mut current.right);

            if let Some(left_node) = current.left.as_mut() {
                my_stack.push(left_node);
            }

            if let Some(right_node) = current.right.as_mut() {
                my_stack.push(right_node);
            }
        }
    }
}



type Link = Option<Box<TreeNode>>;

struct TreeNode {
    value: i32,
    left: Link,
    right: Link,
}

impl TreeNode {
    fn new(value: i32) -> Self {
        TreeNode {
            value,
            left: None,
            right: None,
        }
    }

    // Add child on the left
    fn left(mut self, node: TreeNode) -> Self {
        self.left = Some(Box::new(node));
        self
    }

    // Add child on the right
    fn right(mut self, node: TreeNode) -> Self {
        self.right = Some(Box::new(node));
        self
    }
}

fn invert_binary_tree_iterative(link: &mut Link) { //link is of type &mut Link => &mut Option<Box<TreeNode>>
    let mut my_stack = Vec::new(); // our own stack

    // With `std::mem::swap(&mut node.left, &mut node.right);` we must be able to mutate `node.left` and `node.right`.
    // If we write `if let Some(node) = link {`
    //      * `node` is an immutable reference to the contents of the Option (`&Box<TreeNode>`).
    // We need to mutably dereference `link`, which leads us to use `if let Some(node) = link.as_mut()`
    //      * now `node` is a mutable reference to the contents of the Option (`&mut Box<TreeNode>`).
    // We must continue using `.as_mut()` to propagate mutability throughout the loop.

    if let Some(node) = link.as_mut() {
        my_stack.push(node);

        while let Some(current) = my_stack.pop() {
            // process current node => Swap left and right children
            std::mem::swap(&mut current.left, &mut current.right);

            // If left child exists, push it onto the stack
            // Using `.as_mut()` returns `Option<&mut Box<TreeNode>>`, allowing mutable access to the inner `Box<TreeNode>` so we can modify its children.
            if let Some(left_node) = current.left.as_mut() {
                my_stack.push(left_node);
            }

            // If right child exists, push it onto the stack
            if let Some(right_node) = current.right.as_mut() {
                my_stack.push(right_node);
            }
        }
    }
}

fn preorder_print(link: &Link) {
    if let Some(node) = link {
        print!("{} ", node.value);      // Process current node
        preorder_print(&node.left);     // Traverse left child
        preorder_print(&node.right);    // Traverse right child
    }
}

fn main() { // no main() if this code runs in a Jupyter cell
    // Build the tree:
    //         5
    //      /     \
    //     1       8
    //    / \       \
    //   7   6       4
    let tree = TreeNode::new(5)
        .left(
            TreeNode::new(1)
                .left(
                    TreeNode::new(7)
                )
                .right(
                    TreeNode::new(6)
                )
        )
        .right(
            TreeNode::new(8)
                .left(
                    TreeNode::new(4)
                ) // no child on the right
        );

    let mut root_link = Some(Box::new(tree));
    invert_binary_tree_iterative(&mut root_link);
    preorder_print(&root_link); // 5 8 4 1 6 7
} // end of local scope OR end of main()

Iterative bis

About Rust :

  • Based on V2 (see 189_intro.ipynb) for easy tree building
  • Better invert_binary_tree_iterative ?
  • Preferred solution?
  • YES : tested on the Rust Playground
type Link = Option<Box<TreeNode>>;

struct TreeNode {
    value: i32,
    left: Link,
    right: Link,
}

impl TreeNode {
    fn new(value: i32) -> Self {
        TreeNode {
            value,
            left: None,
            right: None,
        }
    }

    // Add child on the left
    fn left(mut self, node: TreeNode) -> Self {
        self.left = Some(Box::new(node));
        self
    }

    // Add child on the right
    fn right(mut self, node: TreeNode) -> Self {
        self.right = Some(Box::new(node));
        self
    }
}

fn invert_binary_tree_iterative(link: &mut Link) {
    let mut my_stack = Vec::new();

    if let Some(root) = link.as_mut() {
        my_stack.push(root);

        while let Some(node) = my_stack.pop() {
            // Swap left and right children
            std::mem::swap(&mut node.left, &mut node.right);

            // Push non-null children onto the stack
            for child in [&mut node.left, &mut node.right] {
                if let Some(inner) = child.as_mut() {
                    my_stack.push(inner);
                }
            }
        }
    }
}

fn preorder_print(link: &Link) {
    if let Some(node) = link {
        print!("{} ", node.value);      // Process current node
        preorder_print(&node.left);     // Traverse left child
        preorder_print(&node.right);    // Traverse right child
    }
}

fn main() { // no main() if this code runs in a Jupyter cell
    // Build the tree:
    //         5
    //      /     \
    //     1       8
    //    / \       \
    //   7   6       4
    let tree = TreeNode::new(5)
        .left(
            TreeNode::new(1)
                .left(
                    TreeNode::new(7)
                )
                .right(
                    TreeNode::new(6)
                )
        )
        .right(
            TreeNode::new(8)
                .left(
                    TreeNode::new(4)
                ) // no child on the right
        );

    let mut root_link = Some(Box::new(tree));
    invert_binary_tree_iterative(&mut root_link);
    preorder_print(&root_link); // 5 8 4 1 6 7
} // end of local scope OR end of main()
